Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency

Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency

    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
    • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
  • Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency

    Product Details:

    Place of Origin: China
    Brand Name: SURPLUS LIGHTING
    Certification: CE RoHS SAA FCC TUV UL
    Model Number: S-T824W/60AH-01 100LM/W 24W 1500mm Motion Sensor T8 LED tubes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: 1-5US$/unit
    Packaging Details: 25pcs/carton
    Delivery Time: 15-18 working days
    Payment Terms: T/T, L/C at sight, Western Union, Paypal
    Supply Ability: 4500pcs per working day
    Contact Now
    Detailed Product Description
    Item Type: Motion Sensor T8 LED Tubes Luminous Efficacy: 100LM/W
    Chip Brand: Epistar Driver Brand: EMC Approved Driver
    Input Voltage: AC90-277V CCT: 2700K/3000K/3500K/4000K/5000K/5700K/6500K
    Power Range: 9W/14W/18W/20W/22W/24W Main Material: Aluminium Alloy Housing, PC Cover
    Standby Power: 5-8W Standby Period: 30-60 Seconds
    Induction Distance: 5-8 Meters Warranty: 3 Years

    Public Area Using Infrared Sensor 6000K White 1200mm 18W Motion Sensor T8 LED Tube CE SAA Approved 3 Years Warranty







    Working Principle Of T8 1500mm Infrared Sensor LED Tube (Motion Sensor T8 LED Tube)



    Frist, the infrared sensor is installed near the one of end caps in the LED tubes skillfully, the power of the LED tubes will be about 5-8W when the LED tubes are in dormant state, it will meet the requirement of the monitoring. Power consumption in dormant state is 3-5W(standard features), and 0%-100% power in dormant state can be set up in our factory.



    Second, the LED tubes will be full power consumption when the cars or people go through the sensor area. The power will be 24W, it can replace 50W traditional fluorescent tubes easily. It is so convenient for people to park the cars. The power of the LED tubes will be about 5-8W when the people or cars leave away from the induction area.



    Third, each LED tubes is with patent intelligent sensor system, the tubes will be full power consumption when people or cars go through the sensing area, the tubes will be 5W when people or cars leave away from the sensor area in 30 seconds.







    Specification Of 1500mm 24W Motion Sensor T8 LED Tubes Infrared Sensor LED Tube


    Power 24W
    Power factor >0.92
    Luminous efficacy >100LM/W
    Color rendering index >80Ra
    Stand-by power 5-8W
    Beam angle 120°
    Angle of induction 180°
    Induction distance 5-8 meters
    Input voltage AC90-277V
    Color temperature 2700-6500K
    Dimension 28.5x32.5x1198mm
    Warranty 3 years







    Electrical Characteristics Of 1500mm 24W Infrared Sensor Motion Sensor T8 LED Tubes



    All data is under 25℃, unless otherwise specified.

    Symbol Parameter Unit Min. Typ. Max.
    PS Power Consumption W 23.5 24 24.5
    Vin Input Voltage V 85 -- 265
    Vout Output Voltage V 35 37.5 40
    F Input Frequency Hz 50 -- 60
    % Power Factor -- 0.90 0.95 0.98
    % Power Efficiency -- 84% 86% 88%
    Top Operating Temperature Range -20 -- +50





    Why Choose Our Premium 1500mm Motion sensor 24W T8 LED Tubes?



    (1), Superior quality, 3 years warranty.

    (2), More energy saving up to 80% compared to fluorescent tubes.

    (3), Own designing team for new products development.

    (4), Quick delivery time for decent orders.

    (5), More than 8 years export experience.







    Photos About 1500mm 24W Motion Sensor T8 LED Tubes



    Motion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power EfficiencyMotion Sensor 4ft T8 LED Tube 2700k - 6500k LED Sensor Tube High Power Efficiency
