5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved

5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved

    • 5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved
    • 5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved
    • 5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved
    • 5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved
  • 5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved

    Product Details:

    Place of Origin: China
    Brand Name: SURPLUS LIGHTING
    Certification: CE RoHS SAA FCC TUV UL
    Model Number: S-T809W/60AH-01 Dimming 100LM/W 9W 600mm Motion Sensor T8 LED tubes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: 1-5US$/unit
    Packaging Details: 25pcs/carton
    Delivery Time: 15-18 working days
    Payment Terms: T/T, L/C at sight, Western Union, Paypal
    Supply Ability: 3500pcs per working day
    Contact Now
    Detailed Product Description
    Item Type: Motion Sensor T8 LED Tubes Luminous Efficacy: 100LM/W
    Chip Brand: Epistar Driver Brand: EMC Approved Driver
    Input Voltage: AC90-277V CCT: 2700K/3000K/3500K/4000K/5000K/5700K/6500K
    Power Range: 9W/14W/18W/20W/22W/24W Application: Public Area
    Working Temperature: -40~+50°C Main Material: Aluminium Alloy Housing, PC Cover

    Infrared Sensor 5000K White 2FT 9W Motion Sensor T8 LED Tube CE SAA Approved 3 Years Warranty







    Basic Specification Of Our T8 Motion Sensor T8 LED Tubes



    Item NO. Voltage Length PF Luminous CRI Material Source LED Quantity
    T8-0.6m-9W 85V-265V 2ft 0.90 900LM 80 Al+ PC SMD 2835 48pcs
    T8-0.9m-14W 85V-265V 3ft 0.90 1400LM 80 Al+ PC SMD 2835 72pcs
    T8-1.2m-18W 85V-265V 4ft 0.90 1800LM 80 Al+ PC SMD 2835 96pcs
    T8-1.5m-24W 85V-265V 5ft 0.90 2400LM 80 Al+ PC SMD 2835 120pcs
    T8-2.4m-36W 85V-265V 8ft 0.90 3600LM 80 Al+ PC SMD 2835 192pcs







    Tested Datasheet of 600mm 9W Motion Sensor T8 LED Tubes



    2700K 903LM 3000K 915LM
    3500K 929LM 4000K 930LM
    5000K 944LM 5700K  960LM







    Specification Of 600mm 9W Motion Sensor T8 LED Tubes Infrared Sensor LED Tube


    Power 9W
    Power factor >0.92
    Luminous efficacy >100LM/W
    Color rendering index >80Ra
    Stand-by power 3.5W
    Beam angle 120°
    Angle of induction 180°
    Induction distance 5-8 meters
    Input voltage AC90-277V
    Color temperature 2700-6500K
    Dimension 28.5x32.5x588mm
    Warranty 3 years







    Electrical Characteristics Of 600mm 9W Motion Sensor T8 LED Tubes



    All data is under 25℃, unless otherwise specified.

    Symbol Parameter Unit Min. Typ. Max.
    PS Power Consumption W 8.8 9 9.2
    Vin Input Voltage V 85 -- 265
    Vout Output Voltage V 35 37.5 40
    F Input Frequency Hz 50 -- 60
    % Power Factor -- 0.90 0.95 0.98
    % Power Efficiency -- 84% 86% 88%
    Top Operating Temperature Range -20 -- +50






    Application Of 600mm 9W Motion Sensor T8 LED tubes



    (1), Parking lots using motion sensor T8 LED tubes.

    (2), Public area using infrared sensor LED tubes.

    (3), Passage using motion sensor 9W 600mm T8 LED tubes.







    What Is The Feature Of Our Motion Sensor T8 LED Tube Light ?

    1. High brightness Epistar SMD2835 LEDs .
    2. High-end aviation aluminium alloy housing, perfect heat dissipation .
    3. Large beam 180 degree , no dark area, the lighting is very uniform.
    4. Constant current driver with IC .
    5. No RF interference, No flickering or buzzing. Instant start without flickering.
    6. The reaction of our sensor is more quicker then the normal sensor.







    Photos About 600mm 9W Motion Sensor T8 LED Tubes



    5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved5000K White 2FT 9W Motion Sensor LED Tube 600mm SMD 2835 CE SAA Approved
