Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered

Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered

    • Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered
    • Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered
    • Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered
    • Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered
  • Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered

    Product Details:

    Place of Origin: China
    Brand Name: SURPLUS LIGHTING
    Certification: CE RoHS SAA FCC TUV UL
    Model Number: S-T824W/60AH-01 Intelligent Dimming 100LM/W 24W 1500mm Motion Sensor T8 LED tubes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: 1-5US$/unit
    Packaging Details: 25pcs/carton
    Delivery Time: 15-18 working days
    Payment Terms: T/T, L/C at sight, Western Union, Paypal
    Supply Ability: 4500pcs per working day
    Contact Now
    Detailed Product Description
    Item Type: Motion Sensor T8 LED Tubes Luminous Efficacy: 100LM/W
    Chip Brand: Epistar Driver Brand: EMC Approved Driver
    Input Voltage: AC90-277V CCT: 2700K/3000K/3500K/4000K/5000K/5700K/6500K
    Power Range: 9W/14W/18W/20W/22W/24W Main Material: Aluminium Alloy Housing, PC Cover
    Standby Power: 5-8W Standby Period: 30-60 Seconds
    Induction Distance: 5-8 Meters Warranty: 3 Years

    Double Ended Powered High CRI Intelligent Diming Motion Sensor 5FT 24W T8 LED Tubes With 3 Years Warranty







    Basic Datasheet Of Intelligent Dimming T8 5FT Infrared Sensor LED Tube (Motion Sensor T8 LED Tube)



    Model No. Dimension Power Luminous Efficacy CRI Standby Power Warranty
    S-T809W/60AH-01 Ф32.5*28.5*588mm 9W









    95-100LM/W



    >80Ra/>70Ra 3W 3 years
    S-T818W/60AH-01 Ф32.5*28.5*1198mm 18W 4-5W 3 years
    S-T822W/60AH-01 Ф32.5*28.5*1198mm 22W 5W 3 years
    S-T824W/60AH-01 Ф32.5*28.5*1498mm 24W 7W 3 years
    S-T845W/60AH-01 Ф32.5*28.5*2367mm 45W 12W 3 years







    Specification Of Intelligent Dimming 1500mm 24W Motion Sensor T8 LED Tubes Infrared Sensor LED Tube



    Power 24W
    LED Type SUMSUNG/EPISTAR SMD LEDs
    Standby Power 5-7W
    Luminous Efficacy at 5000K 95LM/W
    Input Voltage AC100-277V
    CCT 2700-6500K
    Power Factor >0.9
    Beam Angle 180°
    Induction Beam Angle 115°
    CRI >70Ra/>80Ra
    Ingress Protection IP44
    Junction Temperature <61℃(Ta=30℃)

    Operating

    Temperature

    -30~+50℃
    Lifespan ﹥50000Hrs(Ta=30℃ @L70)
    Application Parking lots, school, public area.
    Main Materials AL6061, PC
    Dimension Ф32.5*28.5*1498±1mm







    Application About Infrared sensorT8 LED Tubes:


    1. Hotels
    2. Conference/meeting room
    3. Commercial Complexes
    4. Residential/Institution Buildings
    5. Schools, colleges & Universities
    6. Hospitals General lighting, Commercial lighting, plant growing lighting.
    7. Refrigeratory, Freezer
    8. Advertisement box,
    9. Parking lot, corridor, ect.







    FAQ


    Q1: What is the Warranty for the Infrared sensor T8 LED tubes?
    A1: For our normal motion sensorT8 LED tubes,we provide 3 years warranty. If any quality problems occured in this period, we will take on the shipping cost and replacement. 5 years warranty is optional.

    Q2: What is color temperature for infrared sensorT8 LED tubes?
    A2: Warm white = 2700K-3200K Natural white = 4000K-4500K Pure white = 5000K-5500K
    Cool white = 6000K-6500K .

    Q3: What is CRI for the infrared sensorT8 LED tubes?
    A3: CRI is a figure which feedback the real objects colors. For LED tubes, the CRI is mostly 70-75Ra,and customers can choose our more than 80Ra motion sensorT8 LED tubes to use at the parking lots or public area.

    Q4: Is there cheap shipping cost to import to our country?
    A4: For small order, express will be best. And for bulk order, sea ship way is best but take much time;For urgent orders, we suggest via air to airport.

    Q5: Can we get support if we have our own market position?
    A5: Please inform us your detailed mind on your market demand, we will discuss and propose helpful suggestion for you to find the best solution.







    Installation steps(double ends powered input):


     Turn off the electricity supply before installation.
     Make sure the circuit of the base is as following A2 and B2. For old circuit originally for
    conventional T8/T10 fluorescent, please following the illustrated steps to adjust the circuit as follow.

    Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered

     For Figure A1 circuit, after removing the starter, the LED tube can be installed directly onto the G13
    base(see Figure A2).
     For Figure B1 circuit, please removing the electronic ballast, and connect L and N to the joints in
    the base separately (see Figure B2).
     After adjusting the circuit, install the LED tube in the same way as installing the traditional
    fluorescent tube light. Turn on the power supply of the base to check whether the tube light is
    working properly or not.







    Photos About Intelligent Dimming 1500mm 24W Motion Sensor T8 LED Tubes



    Intelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended PoweredIntelligent Dimming Motion Sensor LED Tube 5FT 24W T8 LED Tubes Double Ended Powered
