| Place of Origin: | China |
| Brand Name: | SURPLUS LIGHTING |
| Certification: | TUV ENEC CB ENEC+ CE Zhaga-D4i RoHS SAA SASO |
| Model Number: | SL-FL500WxxS3NG |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1-100 USD/unit |
| Packaging Details: | Standard packaging or customized |
| Delivery Time: | 10-18 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 60000pcs per month |
| Power: | 500W | Efficiency: | 180lm/W |
|---|---|---|---|
| Driver: | MOSO / SOSEN / INVENTRONICS | PF: | ≥0.97 |
| IP Rating: | IP66 | IK Rating: | IK10 |
| IES: | 30°/ 60°/90°/15°/ P6 | Warranty: | 5 / 7 / 10 Years |
| Surge Protection: | 10KV / 20KV / 40KV | Dimmable: | DALI-2 / AC Dim/ 0-10V / Timer Dimming |
| Protection Class: | Class I | Ambient Temperature: | 50°C |
| RAL Code: | RAL9006 | Finshing: | C5-M Marine Grade |
30°/ 60°/90° Sportlux Gen3 series C5-M marine grade 500W flood light stadium light data sheet
| Product code | SL-FL500WxxS3NG | SL-FL750WxxS3NG | SL-FL100WxxS3NG |
| Power | 500W | 750W | 1000W |
| Luminous Efficacy | 180lm/W (@4000K/5000K 70Ra) | ||
| Input Voltage | AC100-277V | ||
| LED Type | GUANGYOU 3030(standard)/ TYF 3030/Luminleds LUXEON 3030(optional) | ||
| LED Quantity | 836pcs | 1254pcs | 1672pcs |
| Driver Brand | MOSO / SOSEN (standard); INVENTRONICS / MEAN WELL(optional) | ||
| Surge Protection | Support built-in10KV / 20KV / 40KV SPD | ||
| Ral code | RAL9006 | ||
| CRI | >70Ra | ||
| CCT | 2700K-6500K | ||
| PF | ≥0.97 | ||
| Beam Angle | 30°/ 60°/90° | ||
| Material | ADC12, anti-UV optical PC lens | ||
| Life Span | ≥108,000 hours | ||
| IP Grade | IP66 | ||
| Operating Tem. | -40~50°C | ||
| THD | <12% | ||
15°/ P6 Sportlux Gen3 series C5-M marine grade 500W flood light stadium light data sheet
| Product code | SL-FL500WxxS3NG | SL-FL750WxxS3NG | SL-FL100WxxS3NG |
| Power | 500W | 750W | 1000W |
| Luminous Efficacy | 160lm/W (@4000K/5000K 70Ra) | ||
| Input Voltage | AC100-277V | ||
| LED Type | GUANGYOU 3030(standard)/ TYF 3030/Luminleds LUXEON 3030(optional) | ||
| LED Quantity | 504pcs | 756pcs | 1008pcs |
| Driver Brand | MOSO / SOSEN (standard); INVENTRONICS / MEAN WELL(optional) | ||
| Surge Protection | Support built-in10KV / 20KV / 40KV SPD | ||
| Ral code | RAL9006 | ||
| CRI | >70Ra | ||
| CCT | 2700K-6500K | ||
| PF | ≥0.97 | ||
| Beam Angle | 15°/ P6 | ||
| Material | ADC12, anti-UV optical PC lens | ||
| Life Span | ≥108,000 hours | ||
| IP Grade | IP66 | ||
| Operating Tem. | -40~50°C | ||
| THD | <12% | ||
TUV ENEC ENEC+ Zhaga-D4i CB CE SAA RETILAP INMETRO certified flood light stadium light Features:
Zhaga-D4i luminaires, tested for compliance against Zhaga specifications.
Smart lighting system, DALI-2 / AC dim / Timer dimming.
TUV ENEC, CB, SAA, CE, RETILAP, RoHS certified.
Smart and modern design, the minimalist design puts the focus squarely on the product itself.
Excellent heat dissipation design, sleek appearance design decreases the dust falling on the fixture.Sleek appearance design to decrease the dust falling on the fixture, ADC12 die-casting aluminium high thermal conductivity heat sink to guarantee the perfect heat dissipation.
System lumens output up to 180LM/W, powered by TYF / GUANGYOU 3030 LED, high efficacy and superior robustness in a multi-die, high power package, enabling cost-effective system design.
Provide 5/7/10 year warranty, provide standard 5 year warranty, optional 7/10 year warranty for the luminaires.
A variety of drivers are available, such as MOSO, SOSEN, INVENTRONICS, MEAN WELL.
the 0-10V dimming or DALI control
DALI control. Luminaries can be controlled by a computer.
0/1-10V dimming. Luminance can be divided into 10 level, set it upon your specific requirements.
Professional full cut-off light distribution
Ultra-narrow, narrow and medium beam optics for different kinds of facade and flood lighting applications, available with optics 15°, 30°, 60°,90°, P6.
No light pollution for residential areas.Support built-in 10KV / 20KV /40KV SPD (surge protection device), extends the lifetime of the product while protecting the driver and the luminaires from thunder too.
Optional C5-M grade, chromic treatment for the housing, luminaires come with TUV C5-M test report, marine grade flood light.
Cost-effective and efficient lighting solution for a fast return of investment.
