Home ProductsEnergy-max 210lm/W IP66 Intelligent Solar LED Street Light

210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light

210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light

    • 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light
    • 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light
    • 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light
    • 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light
  • 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light

    Product Details:

    Place of Origin: China
    Brand Name: SURPLUS LIGHTING
    Certification: TUV CB CE RoHS SAA UKCA
    Model Number: SL-ST150E

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: 1-100US$/unit
    Packaging Details: Standard packaging or customized
    Delivery Time: 10-18 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 5,000 units per month
    Contact Now
    Detailed Product Description
    Lifetime: 120,000 Hours (TM21 Report) LED Type: High Power 5050 LEDs
    Warranty: 5 Years Lumens: 210lm/W
    IP Rating: IP66 IK Rating: IK08
    CCT: 1700-6500K / PC AMBER Battery: LiFePO4 25.6V 36Ah

    Energy-max Series 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting Smart City Lighting Solar Powered Street Light



    210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light

    210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Approved Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light



    Energy-max Series 210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light Datasheet



    Product Code SL-ST30E SL-ST40E SL-ST50E SL-ST60E SL-ST80E SL-ST100E SL-ST120E SL-ST150E SL-ST200W
    Power 30W 40W 50W 60W 80W 100W 120W 150W 200W
    Monocrystallinesolar panel power 18V 40W 18V 50W 18V 60W 18V 80W 18V 100W 18V 120W 36V 150W 36V 180W 36V 240W
    LiFePO4 battery capacity 12.8V 18AH 12.8V 24AH 12.8V 30AH 12.8V 36AH 12.8V 42AH 25.6V 24AH 25.6V 30AH 25.6V 36AH 25.6V 48AH
    Luminous Efficacy 210lm/W
    Charging time 6 hours
    Working time Working last for 5-7 Days once full charged (Auto Control)
    LED Type GUANGYOU 5050 / TYF 5050 / LUMILEDS LUXEON 5050
    CCT 1600K-6500K
    Operating temp. -20~65°C
    Beam Angle Type II S, Type II M, Type III S, Type III M
    Material ADC12, anti-UV optical PC lens
    Life Span ≥120,000 hours (L70)
    L90B10 100,000 hours
    IP Grade IP66



    Working time data is based on charging 6 hours in the sunny summer, measured in north latitude 22°, east diameter 113°, Actual working time may be changed due to different installation area, season, environment, direction etc.



    Maintenance of Energy-max series 210lm/W IP66 Integrated Solar LED Street Light 5 Years Warranty



    1. Solar controller is the core component of solar street lights, which has the function of light control, time control, charging and discharging, etc. Keep it dry in use, and do not touch the buttons at discretion. Malfunction must operate in professional instruction.

    2. Solar panel is the longest life span component in the solar street light, which can be used for 35 years. And in use if it doesn't rain for days, the surface of the solar panel will gather much dust, which will affect the power generating efficiency, need manual cleaning when necessary. Keep the solar panel towards the south, correct it timely if there is swing.

    3. LED light source has a long service life, general failure rate is extremely low. Dirt cleaning of the whole light source is needed when using 2 to 3 years in case the dirt resists electricity and reduce the brightness of lights.

    4. The battery itself has certain self-discharge, when the All In One Solar Light is not in use for a long time, please take out the light regularly for charging in the sun.



    Trouble shooting for Energy-max series IP66 IK08 Integrated Solar LED Street Light 5 Years Warranty



    Phenomenon Cause Inspection methods Solution

    Lights

    not work

    Switch does not turn on Check whether the switch turns on Turn on the switch
    Switch failure Make the switch short circuit, if it is still lighting up, could judge the switch failure. Replace Switch
    Battery runs out Long rainy day or wrong installation site could not charge enough power. Open the system, disconnect the battery and use multimeter to check the voltage of the battery, if voltage less than 11V, then could judge battery runs out or low power cause system could not work. Charge battery by solar panel in daytime, and turn off the switch at night to stop discharge, like this, 2 days could full charge the battery.
    LED Failure Firstly, adjust the DC power supply to voltage 9V and current less than 1A, then connect the positive and negative electrode of DC power supply to LED, if LED could not light, could judge LED failure. If confirming LED failure, please contact us to return and replace.

    Short

    lighting time

    Low battery

    Wrong installation or dust and leaves cover on solar panel cause not enough solor power to battery.

    1. Check whether there is dust or leaves covering on the solar panel. 2. Open the system, disconnect the battery and use multimeter to check the voltage of the battery, if voltage less than 11V, that could judge battery runs out or low power cause system could not work.

    1. Charge battery by solar panel in daytime, and turn off the switch at night to stop discharge, like this, 2 days could full charge the battery.

    2. Clean the solar panel.

    Battery Failure

    Open the light and check if battery is dispalced or outer has been damaged .

    Battery maturing, lights used more than 2 years.

    1. If damage caused by transportation, please return to our factory for repairing or replacement.

    2. Contact us to buy the same type battery if battery maturing.

    No induct Sensor Failure Move in the range of detection under the half power lighting condition, if light not turns to full power ,could judge the sensor failure. If confirming failure caused by controller or sensor, please return to our factory for repairing or replacement.
    Flashing light Controller (timer) setting wrong Intelligent mode opens due to an exceeding output power of the controller and light flashing. Return to our factory to reset or replace the products.



    210 lm/W 150W IP66 Integrated Intelligent Solar LED Street Light TUV CB CE SAA Certified Solar Lighting All in one solar LED street light solar powered LED street light solar LED parking lot light solar energy street light
